XY-2B Rotary Head Core Drilling Rig XY-2B manufacturer from China Gold Mechanical & Electrical CO.,LTD

Payment Terms:	T/T,L/C,D/A
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: XY-2B

Packing: wooden case

Application: Others

Brand Name: GOLD

Means of Transport: Ocean,Air

Delivery Date: 2 weeks

Type: Drilling Rig

drilling rig: rotary head drilling rig

It's used in engineering geological, hydrogeological, water well and pile grouting hole drilling.

XY-2B drillrig derived from xy-2 drillrig, it not only keeps all performances of xy-2 drill, but also adds spindle inner hole diameter to 96mm. It is especially available for constructions of hydroelectric power station, highway, railroad and harbor etc. In common with xy-2 drill in all design but hydraulic chuck and rotary head modified.

Technical Specifications

Drilling capacity (m)	Φ73 rod	100
	Φ60 rod	200
	Φ50 rod	380
	Φ42 rod	530
Spindle speed(r/min)	Forward	57;99;157;217;270;470;742;1024
	Reverse	45;212
Max torque(Nm)		2760
Angle renge		0-90°
Spindle max pull force(KN)		60
Spindle stroke (mm)		600
Hoist max lift capacity with single rope (KN)		30
Spindle inner dia (mm)		76
Oil pump		SCB32/12
Power unit	Electric motor	Y180L-4,22Kw
	Diesel engine	395K2,19.85Kw
Inner dia of spindle (mm)		2150×900×1690
Drill weight(excluding power)(kg)		950
